Hlavné detaily
- Hladké zagulatené vidlice, vybavené vstupnými / výstupnými
pomocnými valcami - Výber širších rámov, rovnako ako možnosť kratších alebo dlhších vidlíc
- Prémiová pumpa s funkciou Quick Lift (až do 150kg)
- Rukoväť Premium Line
- Vhodné pre bežné používanie
- 12 mesiacov záruka
Modely
| Manufacturer (abbreviation) | HYSTER |
|---|---|
| Manufacturer's type designation | ELPM - PLPM |
| Drive: electric (battery or mains), diesel, petrol, fuel gas | Manual |
| Operator type: hand, pedestrian, standing, seated, order-picker | Manual + Tiller |
| Rated capacity/Rated load Q (t) | 2.5 |
| Load centre distance c (mm) | 600 |
| Load distance, centre of drive axle to fork x (mm) | 985 |
| Wheelbase y (mm) | 1215 |
| Unladen Weight kg | 76 |
| Tyres: rubber, polyurethane, Vulkolan® front / rear | Rubber PU Nylon |
| Tyre size, front | 200x50 |
| Tyre size, rear | 80 x 93 or 80 x 70 |
| Wheels, number front / rear | 2/2 or 2/4 |
| Track width, front b^ (mm) | 180 |
| Track width, rear bn (mm) | 435 |
| Lift Height h 9 (mm) | 200 |
| Height of tiller arm in working position h u (mm) | 1225 |
| Height, lowered h n (mm) | 85 |
| Overall length l1 (mm) | 1560 |
| Length to face forks l, (mm) | 410 |
| Overall width b1/b 9 (mm) | 520 | 685 |
| Fork dimensions s/e/l (mm) | 50 1560 1150 |
| Outside fork width b5 (mm) | 520 | 685 |
| Ground clearance, centre of wheel base m 9 (mm) | 30 |
| Load dimension b^ x l6 crossways b1 2 x l6 (mm) | 1548 |
| Aisle width with pallets A s t (mm) | 1748 |
| Turning radius Wa (mm) | 210 |
